OEM JLR Certified Equipment
Meets JLR OEM specifications and approval standards.
GYSPOT PTI NEO
-
The GYSPOT PTI NEO is an automatic spot welder designed for the assembly of car body panels. Its liquid-cooled gun with integrated transformer is the lightest on the market, weighing just 9.7 kg when fitted with the G1 arm. Compact and manoeuvrable, it is ideal for workshops where space is limited. It features an ergonomic, user-friendly colour interface.
Gyspot PTI-S7 22V Evolution
-
The Gyspot-PTI-s7-220v-Evolution is the ideal answer to the welding requirements of high strength steels (UHSS/boron), with a clamping force of 550daN, with 8bars air pressure, and a welding current that can reach 14 500Amps
Its C-clamp integrates a high-tech transformer
Brings a solution to limited power supply issues, as it can operate with 16 Amps to 25 Amps fuses only
Operation is extremely easy thanks to the automatic welding parameters setting in easy mode
Gyspot PTI Genius (6M) - 208V
-
The GYSPOT INVERTER PTI-G spot-welder is the machine of the future. Therefore the onboard intelligence guarantees full automation, offering body shops the ability to increase their efficiency. The Genius G-clamp with pneumatic over-opening, easy-arm positioning without adjustment, motorized overhanging arm that provides a wide working area. This makes the GYSPOT INVERTER PTI-G the most advanced machine for the active collision repair shop.
Motorized, Adjustable & Ergonomic Overhanging Arm
Extends up to 120cm from the power source
Motorized overhanging arm to adapt to the working height.
Adjustable in height from 159 to 253 cm
Rubber protections at the end of moving parts
Creates easy access to the work area
Smart Welding
AUTO Mode: the machine automatically recognizes – steel type, sheet-metal thickness, Panel bond presence, and insulating material between HSS/VHSS/UHSS/Boron sheet-metal.
Traceability: The recording feature saves the characteristics of each welding spot performed to the SD card provided
Easy transfer of saved reports to PC.
Robust and Mobile
Reinforced and maneuverable trolley with 30-litre coolant tank.
Expander on the front wheels for better stability.
Integrated 6-arm support
Specifications
Welding current: 14,500 A.
Clamping force: 550 daN with 8 bar air pressure.
Liquid cooling of the entire transformer, rectifier, electrodes, and caps.
The new design of the G-clamp cylinder and welding algorithm maximizes productivity
User-friendly navigation using the 5.7″ LCD screen.
Automatic adjustment of the pressure between electrodes.
Spot count feature to determine when you need to change the caps.
-
A digital MIG/MAG double pulse generator with 3 integrated wire feeders
An extremely advanced machine with 57 synergic curves providing an exceptional arc quality
Versatile; it will hold 3 different torches to weld steel, aluminum and brazing (CuSi3/CuAl8)
User friendly interface and very precise wire feed make an outstanding quality weld on very thin sheets
Autopulse 320-T3
GYSDUCTION AUTO COMPLETE (Generator+3 inductors)
-
GYSDUCTION AUTO is a powerful, instantaneous induction heating system. Ideal for bodywork, mechanics and maintenance:
- Removing all adhesives, logos, trim and mouldings
- Removing glued windows while preserving the trim (rear window, quarter panel, panoramic roof, etc.)
- Remove gravel guards and seals
- Free and unblock mechanical parts (bolts, screws, spark plugs, injectors, etc.)
- Remove minor dents from the bodywork without touching up the paintwork
COMPLETE AUTO GYSDUCTION Pack :
• AUTO GYSDUCTION
• 3 cables
• 1 window inductor
• 1 adhesive inductor
• 1 release inducer
• 1 pedal
MIG WIRE REEL ALU AlMg5 Ø0.8 - 0.5 KG D.100 - ER5356 / S Al 5356
MIG WIRE REEL ALU AlMg5 Ø1.0 - 2 KG D.200 - ER5356 / S Al 5356
DIE KIT RMB 02 (Jaguar / Land Rover Group) FOR RIVETERS 10T
Dolly Toe 511110
Dolly Universal 511112
Bumping hammer round face 511039
Molding wedges
Set of alu drill bits 1.0mm to 10.0mm
7” Straight jaw locking pliers
10” Straight jaw locking pliers
10” Curved jaw locking pliers w/cutter
10” long nose locking pliers
10” grip locking pliers
Sheet fastening kit
JLR Approved Hand Tools
Vacuum assist random orbital sander
Heat gun, 1400w
Digital temp gauge
Dust particle mask
Tool Storage cabinet
4-ton porta power set
Rivet sizer (Digital caliper)
90-degree angle drill, reversable 3/8”
Vario Drill, pnumatic
Step drill bit 4mm-22mm
2” wire wheel
Hammer, plastic tip 24oz
Hammer, picking & dinging
3M File Belt Sander, .6 hp 1/2” File
Huck AK175A by Air Power Riveter
Adjustable File Holder
Standard 14” Body File
Straight Shell 14” Body File
Left Hand 10” Aviation Tin Snips
Right Hand 10” Aviation Tin snips
J-Type Axial Clamp Qty 2
LL-Type Axial Clamp Shallow Qty 2
JJ-Type Axial Clamp Deep
Qty 2
L-Type Axial Clamp Qty 2
W-Type Axial Faced Clamp
Qty 2
U-Clamp 12” Locking Pliers Qty 2 (GR-14512)
Straight Jaw 5” Locking Pliers Qty 2
(GR-11205)
Grinding Protection blanket
Pnumatic body saw
Sawblade 32tpi 10pk
Sawblade 24tpi 10 pk
WS90 Daimler version spot drill
Hammer, Wide nose cross peen
Hammer, Ball peen
Spoon, High crown, inside 15”
Spoon, Light dinging 10”
Steel Heel dolly
Anvil dolly
Sander, long board with dust extraction
