OEM Hyundai Certified Equipment

The GYSPOT INVERTER PTI-G spot-welder is the machine of the future. Therefore the onboard intelligence guarantees full automation, offering body shops the ability to increase their efficiency. The Genius G-clamp with pneumatic over-opening, easy-arm positioning without adjustment, motorized overhanging arm that provides a wide working area. This makes the GYSPOT INVERTER PTI-G the most advanced machine for the active collision repair shop.

Motorized, Adjustable & Ergonomic Overhanging Arm

Extends up to 120cm from the power source

Motorized overhanging arm to adapt to the working height.

Adjustable in height from 159 to 253 cm

Rubber protections at the end of moving parts

Creates easy access to the work area

Smart Welding

AUTO Mode: the machine automatically recognizes – steel type, sheet-metal thickness, Panel bond presence, and insulating material between HSS/VHSS/UHSS/Boron sheet-metal.

Traceability: The recording feature saves the characteristics of each welding spot performed to the SD card provided

Easy transfer of saved reports to PC.

Robust and Mobile

Reinforced and maneuverable trolley with 30-litre coolant tank.

Expander on the front wheels for better stability.

Integrated 6-arm support

Specifications

Welding current: 14,500 A.

Clamping force: 550 daN with 8 bar air pressure.

Liquid cooling of the entire transformer, rectifier, electrodes, and caps.

The new design of the G-clamp cylinder and welding algorithm maximizes productivity

User-friendly navigation using the 5.7″ LCD screen.

Automatic adjustment of the pressure between electrodes.

Spot count feature to determine when you need to change the caps.
